Goodyear 3B12-304 Air Spring 578-93-3-100 Triple Rubber Air Bellow FT 330-29 503 Contitech

Detail produk:

Tempat asal:	Meksiko
Nama merek:	Goodyear
Sertifikasi:	ISO/TS16949, ISO9001
Nomor model:	3B12-304

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	5pcs
Harga:	USD159.9-299.9/PC
Kemasan rincian:	Kotak Karton yang kuat atau sebagai Kebutuhan Pelanggan
Waktu pengiriman:	3-7 Hari Kerja
Syarat-syarat pembayaran:	L/C, T/T, Western Union atau lainnya
Menyediakan kemampuan:	1000PCS/Minggu

Kontak

Detil Deskripsi produk

Nomor Suku Cadang Pabrikan:	3B12-304 \| Permintaan Khusus	Merek:	Tahun yang baik
Bahan:	Karet alam	Paket:	Karton Coklat
Goodyear Bellows:	Nomor telepon 578-93-3-100	Contitech:	FT 330-29 503
Warna:	Hitam	batu api:	W01-358-8006
Menyoroti:	Goodyear 3B12-304 Air Spring , 578-93-3-100 Triple Rubber Air Spring

Goodyear 3B12-304 Air Spring 578-93-3-100 Triple Rubber Air Bellow FT 330-29 503 Contitech

Deskripsi Produk

Goodyear Triple Bellow Air Spring: 3B12-304

Goodyear Triple Bellow Air Spring: 3B 12-304

Goodyear Triple Bellow Air Spring: 3B12 304

Goodyear Bellows Nomor: 578-93-3-100

Goodyear Bellows Nomor: 578 93 3 100

Goodyear Bellows Nomor: 578933100

3B12-304 Nomor referensi silang

Automann	ABSP3B22R-8006	Contitech	64568
Contitech	FT 330-29 503	Firestone	W013588006
Penjaga beban	SC2132	Suspensions Inc.	200620
Segitiga	4430/4503	TRP	ASP1710

Data Teknis
Lubang plat atas/Stud Qty: 2
Diagram piring atas: 9
Lembar atas C sampai C Diameter: 6.2
Piring bawah lubang Stud Qyt: 2
Diagram piring bawah: 9
Lembar bawah C sampai C Diameter: 6.2
Perataan lempeng bawah: paralel
Tidak.
Kurung:Tanpa
Min Tinggi: 4.8
Tinggi maksimum: 18

Goodyear Triple Air Spring

Jumlah bellow	Nomor Bagian	Nomor OEM
578-93-3-100	3B12-300	Contitech FT 330-29 431 Firestone W013588008 Firestone W013588025
578-93-3-100	3B12-301	Contitech FT 330-29 432 Firestone W013588010 Firestone W013588030
578-93-3-100	3B12-303	Contitech FT 330-29 434 Firestone W013588018
578-93-3-100	3B12-305
578-93-3-100	3B12-310	Contitech FT 330-29 466 Firestone W013588027
578-93-3-100	3B12-312	Contitech FT 330-29 525 Firestone W013588033
578-93-3-100	3B12-315	Contitech FT 330-29 547
578-93-3-100	3B12-319	Contitech FT 330-29 413 Firestone W013588032
578-93-3-100	3B12-324
578-93-3-100	3B12-328	Contitech FT 330-29 546 Firestone W013587994
578-93-3-100	3B12-329	Contitech FT 330-29 546 Firestone W013587990 Firestone W013587995
578-93-3-100	3B12-335	Contitech FT 330-29 520 Firestone W013587996
578-93-3-100	3B12-338
578-93-3-100	3B12-342
578-93-3-103	3B12-322	Firestone W013588042
578-93-3-103	3B12-323	Firestone W013588048
578-93-3-103	3B12-325	Firestone W013588047
578-93-3-103	3B12-326
578-93-3-103	3B12-347
578-93-3-104	3B12-337
578-93-3-105	3B12-415	Contitech FT 330-29 554 Firestone W013588038
578-93-3-105	3B12-416	Firestone W013588039
578-93-3-350	3B12-351
578-93-3-350	3B12-354	Contitech FT 530-32 336 Firestone W013587808
578-93-3-350	3B12-356	Contitech FT 530-32 329 Firestone W013587798
578-93-3-350	3B12-359	Contitech FT 530-32 325 Firestone W013587816 Firestone W013587818
